Diameter DN10~DN150
Electrode material 316L, Hb, Hc, Ti, Ta, Pt
Lining material PTFE, PFA, F46
Medium Conductive liquid
medium conductivity ≥5μs/cm , softened water is 20μs/cm
Accuracy grade ±0.5%RS-± 1.0% RS
supporting converter model MF710/720/730 (split type) / MF740
Velocity range 0.1m/s -10m/s
Working temperature -25℃~120℃ (split 150℃)
Working pressure 0.6MPa~1.6MPa( caliber)
protection class IP65, IP67, IP68 (split)
power supply 220VAC, 24VDC, battery powered
installation form integrated, split
