Temperature
Temperature measurement range Can be measured to-20℃~+1000℃
Accuracy ±3Kor±3%,Use the maximum value(This accuracy applies only to ambient temperature 15-50℃，The temperature of the object being measured 15-200℃)
Emissivity default 0.95（0.01-1 adjustable）
Background reflection temperature compensation Yes
Radiation coefficients adjust. Yes
Imaging performance
Response time 250ms
Thermal sensitivity 200mk
Frame frequency ≤6Hz
Infrared frequency range 8μm-14μm
Visible lens 300000 pixels
Focusing way fixed
Infrared image resolution 1024 pixels （32x32）
Viewing Angle 33°
Graph presentation
Color palette Iron red, rainbow, gray
Infrared visible light fusion 0%(full thermal imaging)，25%，50%，75%，100%（All the visible light）。
Display type 2.4”TFT LCD
Display resolution 240*320 pixels
Image capture and data storage
Image capture Freeze images to allow viewing before saving
storage medium It has a built-in memory of 8M (7.8m can be used, and can store 52 photos), supports the expansion of 32G Micro SD memory card at most, and only supports SD card in FAT32 file format.
Image format .bmp
View stored images Press the button to turn the page on the screen and display all saved images.
General parameters
Battery 3*1.5V AAA or 1PC 18650 battery
Instrument current and voltage Current :About 160mA，voltage :3.6~4.2V
Overall dimensions 210*101*60mm
Instrument net weight 220g (no batteries)
Operating temperature and humidity -10~40℃ ＜85%RH
Storage temperature and humidity -20~75℃ ＜85%RH
