Desktop Vacuum Coating Machine with Heat Cover GN-VC25H

This product is widely used in various high temperature coating research, such as ceramic film, crystal film, battery material film, special nano film; can adapt to the development of science and technology in the future high temperature film formation.
1.With micrometer adjustable film applicator width 250mm
2.The digital display temperature control drying system, the maximum working temperature is 200 ° C;
3.Digital display timer, free to set the drying time;
4.The coating speed is adjustable within the range of 0 to 100 mm/sec
5.Vacuum aluminum plate for quick placement or removal of the substrate
6.The stroke can be adjusted by the stroke switch between 10 and 300 mm
7.with adjustable coating thickness (0.01mm accuracy); small size and space saving
8.The appearance is exquisite, and the sheet metal adopts three-dimensional geometric design, which is simple and beautiful;
9.Place the coated film on the vacuum plate, start the power supply, turn on the vacuum, and the pole piece is adsorbed on the vacuum plate;
10.Place the applicator on the pole piece and place the coating slurry
11.Start the coating film, the film coating device automatically pushes the film applicator to walk, and automatically coats the film.
12.Remove the applicator and the push rod, cover the heating cover, set the heating temperature and time, and heat and dry
13.After the drying is completed, the hot cover is developed, and the coated film is taken out, and the coating device is reset.
Hot drying temperature adjustment: As shown in Figure 1, the green number on the temperature controller indicates the current temperature setting value. The red color indicates the current temperature detection value. Press “up” and “down” keys to select temperature value.
14.Hot drying time adjustment: When the temperature reaches the current set value, the timing operation starts. If the adjustment timing, pressed the following dialing code can be adjusted.
