3.2V 3000mAh 26650
  • Seen : 200 View

0
3.2V 3000mAh 26650


Items

Parameter

Battery model

MC-26650

Nominal voltage

3.2V

Minimum capacity

3800mAh@25ºC
Charging voltage

3.65V

Discharging cut-off voltage

2.5V

Standard charging

0.2C /3.65V

Max charging

1.0C /3.65V

Standard discharging

1C/2.5V

Max discharging

continuous discharge

1.0C/2.5V

non-continuous discharge

2.0C/2.5V

Operation voltage

2.5-3.65V
Operating temperature

Charging: 0°C ~ 45°C

Discharging: -20°C ~60°C

Storage (At 50% SOC and specified temp,
recoverable capacity in % vs time )

-10ºC~25ºC

(12 months ≥85% )

-10ºC ~45ºC

(6 months ≥85% )

-10ºC~55ºC

(1 month ≥90% )

20±5ºC is the recommended storage temperature

Visual Inspection

There should not be any remarkable scratches, cracks,
bolts, cauterization, deformations, swelling, leakage
and so on the surface of the cell.

Warranty 12 months
