VLC electric small inline water sump centrifugal pump is widely used in primary water treatment plants, sewage treatment plants, power plants, metallurgy, iron and steel industry, mining,
municipal engineering and hydraulic engineering fields, etc.Transport water and containing solid particles,such as iron, sand, coal, etc.) of sewage, sea water, industrial water is
corrosive, solution, etc.;Conveying liquid temperature does not exceed 80 ºC. Flow: 60 ~ 8400 m3 / h head: 10 ~ 300 m. VLC type vertical long axis pump suction vertical downward,
export levels, single base installation.
Performance Range:
Capacity Q:60~8400 m3/h
Head H:12.5~94.5 m
Application:
VLC electric small inline water sump centrifugal pump is widely used for water treatment, sewage water treatment, power plant, Iron and steel industry, mining, public engineering
irrigation, and water conservancy and so on. It can also be used to transport clean water and sewage water which is contain some solid particle ( scrap iron, gravel, braize)
corrosive industrial sewage water, sea water, the temperature of transport liquid can not exceed 80ºC.
Description of type:
150VLC3-90A-L
150 - pump discharge diameter
VLC - Vertical long shaft pump
3 - Impeller stage(Omitting 1 if the pump only one stage)
90 - Design point head without cut.
A - Impeller outer diameter cutting code.
L - Submerge depth
VLC vertical long shaft pump's suction straight down, discharge horizontal , single basic installation.
Pump suction installs filter, and with suited hole, it not only prevent the bigger particle enter into pump and broken pump, but also ensure inflow water area.
Lower suction loss, improve pump efficiency.
Take a full Consideration of the impeller and vane abrasion resistance, extend the life of impeller and other wear parts.Multistahe Ipmeller and defuser are adapt to varies head.
The Impeller can balance its' axial force by balance hole, there is replaceable special dam type seal ring installed the throat bush and frame plate liner insert that can protect
impeller and casing. It can prevent impurity sediment enter into the suction seal ring gap, this can exceed the using life of seal ring and impeller
