Model
5H-15
5H-16
5H-22
5H-30
5H-32
Capacity
Paddy(kg)
3000-15000
6500-16000
4500-22000
4500-30000
4500-32000
Outer dimension
(mm)
Length*Width*Height
3791*2250*9385
4150*2190*12000
4100*3500*9865
4950*3850*11815
4680*4080*13000
Machine quality(kg)
3500
3850
4800
5300
8300
Electricity
Voltage
Three phase 380V/ single phase 220V, 50Hz
Rate power(kw)
8
9.6
8
16.2
16.5
Performance
Feeding time(min)
40
43
45
57
58
Dis charge time(min)
48
50
50
60
60
Drying rate(%/h)
Rice, wheat, rape 0.6~1.2%/ h Corn 1.2~2.6%/ h
Safety devices
Wind pressure switch, temperture control device, electrical filter alarm device, full alarm device, fault alarm device, leakage protection device, guardrail.
Standard equipment
Automatic moisture meter, hopper, dust machine.
Optional equipment
Hot-air fumace, steam heat exchanger, heat-conducting oil heat exchanger, outlet pipe, exhaust pipe.
Declaration:
The price showing here only for your reference,It is may not the final actual transaction price,due to raw material costs and exchange rate changes frequently, also your requirements(includes but is not limited to the specification, model, workmanship,quantity per time, quality requirements,customized service) different to this product information.
