Outdoor optical cable sheathing line
Outdoor optical cable sheathing line
  • Seen : 208 View

0
Outdoor optical cable sheathing line

Features:

1. The materials are PVC, LDPE, MDPE, HDPE, LSZH.

2. The temperature control is controlled by imported OMRON temperature control meter, and the temperature control is accurate.

3. The production line system can automatically adjust the outer diameter of the wire diameter through the diameter feedback function, and the wire diameter is stable.

4, International industrial computer technology control system FIBERCAN program with high degree of automation, it can be linked with MES, ERP systems, real time tracking and managing production.

5. The main control systems and components are international famous brands, and the production line has high stability and reliability.



Technical Parameters
1. Structure speed: 100m/min

2. Sheath outer diameter; 6.0mm-35.0mm

3, cable core diameter: 4.2mm-30mm

4, extruder specifications: 90mm

5, reel sizes: 800mm-1600mm

6, cable reel size: 800mm-1600mm

7, additional loss: ≤ 0.02db / km (sm fiber)

8, the length of the production line: ≤ 55m

9, power supply requirements: 130KVA, AC380V ±10% 50HZ three-phase five-wire

Saler Company Information

Company : Dongguan Gongfei Smart Technology Co., Ltd
Mobile : 008613826951514
Phone : 008676984597286
More Information : View
