.The standard configuration is 4 axes and three links, and the rotary axis is determined by the parameter, and can be adapted with 4 axes link;
2.Max. traverse speed reaches 30m/min, max. feedrate reaches 15m/min;
3. Linear, exponential and S acceleration/deceleration is optional;
4.Pitch error compensation, backlash compensation, tool length compensation, tool wear compensation and tool nose radius compensation;
5. Convenient management with multilevel operation password;
6. Chinese and English display window selected by the parameter
7. 56M program memory capacity to store 400 programs and back stage edit function;
8. standard RS232 and USB interface to realize the bidirectional transmission of programs, parameters and PLC programs between CNC and PC;
9. DNC control and its baud rate can be set, up to 115200;
10. Embedded PLC can realize the various of logic control functions; its ladder can be edit , uploaded and downloaded on-line;
11. standard 48 input/48 output interfaces, I/O can be extended(optional function);
12. Auto/Manual switch by manual interference function;
13. MPG interrupt and Step interrupt function can execute the translation of coordinate system in the course of automatically running;
14. Edit programs can be executed in automatically running;
15. Rigid tapping and soft tapping are set by the parameter;
16. Three-gear shifting function, switch frequency conversion output voltage in max. spindle speed according to the corresponding gear;
17. Rotary, scale, polar coordinates and many kinds of fixed cycle function;
18. Index information function to be convenient to operation and maintenance;
19. History alarm and operation log to be convenient to maintenance.
