Plate exchangers are a type of heat exchangers in which the exchange surface between two hot and cold fluids is created by plates. The material of the plates is very diverse depending on the type of fluid, which includes Snail-Titanium-Nickel and...
The basis of operation of this type of converters is based on the principle of two fluids with different temperatures passing by each other. The plates in the exchanger take over the heat exchange between two fluids.
Dimensions and size
Due to its high efficiency, the dimensions and volume of plate converters are about 80% smaller than other types such as shell & tube, therefore, in terms of installation, service and repairs, as well as the design of the structure at height, it is very important and helps to reduce costs.
service time
Due to the high eddy current, the formation of deposits on the surfaces of the converter is very low, and the service time and useful life of the Nesit converter is much longer than other types. Also, due to the simple mechanism and light weight, periodic maintenance and repairs can be done with minimal cost.
Washer heat exchangers
This type is one of the most common types of plate converters, in which the converter plates are separated from each other with special washers. The plates are placed between two metal frames and tightened by long screws from the surrounding and form the converter assembly. These converters have a maximum working pressure of 20 Bar and a working temperature of 200 degrees Celsius.
Constituent components of washer plate converters
Gasket converters have a simple structure as follows:
1-Front frame 2-Rear frame 3-Vertical support
4- Upper guide rod 5- Lower guide rod 6- Rear frame roller
7-master bolts of converter 8-inlet nozzles 9-washer of converter
10-converter plate 11-specification plate
