Plate Pack Liquid Liquid Coalescer
Plate Pack Liquid Liquid Coalescer
  • Seen : 199 View

0
Plate Pack Liquid Liquid Coalescer

One of the types of separators widely used in the oil and gas and petrochemical industries are plate separators. This type of separator consists of parallel inclined plates with equal distances. These types of separators increase the efficiency of liquid-liquid gravity separators. These plates provide the conditions that the suspended droplets of the dispersed phase connect to each other by placing on the plates and form larger droplets and they can be separated from the continuous phase more easily due to the force of gravity. The slope of the plates causes the phases to move towards the boundary between them. The flow regime between the plates must be smooth for good separation to occur. The slope and distance between the plates are determined according to their design type. Usually, the angle of the plates is 45 to 60 degrees and their distance from each other can vary from 10 to 100 mm.

Saler Company Information

Company : Azar Energy
Phone : 00984134445982
More Information : View
